How thick is 10 gauge steel?
0.1345 in3.42 mm
10 gauge mild steel is 0.1345 inches (3.42 mm) nominal. This value is for uncoated carbon steel; stainless steel, galvanized steel, and aluminum use different thicknesses for the same gauge.
← All calculatorsXeon NC / Engineering toolsSheet Metal Gauge
Scroll to exploreSame number.
Different thickness.
Convert steel, stainless steel, aluminum, and galvanized sheet gauge to thickness in inches and millimeters. Compare nominal values with the decimal thickness specified for your part.
View the thickness chart Use the gauge converterPowered by Xeon NC
Convert a gauge to inches and millimeters, or find the closest gauge to a measured thickness. The selected material stays with you in either direction.
A higher gauge number means a thinner sheet. A gauge match is a reference value, not a measurement tolerance or a stock guarantee.
Gauge values are nominal. Use decimal thickness on your drawing and quote.
Nominal thickness in each metal, with nearby Xeon catalog stock shown separately. Expand a row for stock and weight details, or choose a green stock chip to open its manufacturing checks. Specify the decimal thickness on your drawing.
Select a gauge to narrow the chart. Expand a row for details; scroll within the table to compare all metals.
| Gauge Number | Aluminum B&S · ASTM B209 | Mild Steel MSG · A1008 / A1011 | Stainless MSG SS · ASTM A240 | Galvanized MSG Galv · ASTM A653 |
|---|---|---|---|---|
| 3▸gauge | 0.2294″5.83 mm | 0.2391″6.07 mm | 0.2500″6.35 mm | —no published gauge |
| 4▸gauge | 0.2043″5.19 mm | 0.2242″5.69 mm | 0.2344″5.95 mm | —no published gauge |
| 5▸gauge | 0.1819″4.62 mm | 0.2092″5.31 mm | 0.2187″5.55 mm | —no published gauge |
| 6▸gauge | 0.1620″4.11 mm | 0.1943″4.94 mm | 0.2031″5.16 mm | —no published gauge |
| 7▸gauge | 0.1443″3.67 mm | 0.1793″4.55 mm | 0.1875″4.76 mm | —no published gauge |
| 8▸gauge | 0.1285″3.26 mm | 0.1644″4.18 mm | 0.1719″4.37 mm | 0.1681″4.27 mm |
| 9▸gauge | 0.1144″2.91 mm | 0.1495″3.80 mm | 0.1563″3.97 mm | 0.1532″3.89 mm |
| 10▸gauge | 0.1019″2.59 mm | 0.1345″3.42 mm | 0.1406″3.57 mm | 0.1382″3.51 mm |
| 11▸gauge | 0.0907″2.30 mm | 0.1196″3.04 mm | 0.1250″3.17 mm | 0.1233″3.13 mm |
| 12▸gauge | 0.0808″2.05 mm | 0.1046″2.66 mm | 0.1094″2.78 mm | 0.1084″2.75 mm |
| 13▸gauge | 0.0720″1.83 mm | 0.0897″2.28 mm | 0.0938″2.38 mm | 0.0934″2.37 mm |
| 14▸gauge | 0.0641″1.63 mm | 0.0747″1.90 mm | 0.0781″1.98 mm | 0.0785″1.99 mm |
| 15▸gauge | 0.0571″1.45 mm | 0.0673″1.71 mm | 0.0703″1.79 mm | 0.0710″1.80 mm |
| 16▸gauge | 0.0508″1.29 mm | 0.0598″1.52 mm | 0.0625″1.59 mm | 0.0635″1.61 mm |
| 17▸gauge | 0.0453″1.15 mm | 0.0538″1.37 mm | 0.0563″1.43 mm | 0.0575″1.46 mm |
| 18▸gauge | 0.0403″1.02 mm | 0.0478″1.21 mm | 0.0500″1.27 mm | 0.0516″1.31 mm |
| 19▸gauge | 0.0359″0.91 mm | 0.0418″1.06 mm | 0.0438″1.11 mm | 0.0456″1.16 mm |
| 20▸gauge | 0.0320″0.81 mm | 0.0359″0.91 mm | 0.0375″0.95 mm | 0.0396″1.01 mm |
| 21▸gauge | 0.0285″0.72 mm | 0.0329″0.84 mm | 0.0344″0.87 mm | 0.0366″0.93 mm |
| 22▸gauge | 0.0253″0.64 mm | 0.0299″0.76 mm | 0.0313″0.80 mm | 0.0336″0.85 mm |
| 23▸gauge | 0.0226″0.57 mm | 0.0269″0.68 mm | 0.0281″0.71 mm | 0.0306″0.78 mm |
| 24▸gauge | 0.0201″0.51 mm | 0.0239″0.61 mm | 0.0250″0.64 mm | 0.0276″0.70 mm |
| 25▸gauge | 0.0179″0.45 mm | 0.0209″0.53 mm | 0.0219″0.56 mm | 0.0247″0.63 mm |
| 26▸gauge | 0.0159″0.40 mm | 0.0179″0.45 mm | 0.0188″0.48 mm | 0.0217″0.55 mm |
| 27▸gauge | 0.0142″0.36 mm | 0.0164″0.42 mm | 0.0172″0.44 mm | 0.0202″0.51 mm |
| 28▸gauge | 0.0126″0.32 mm | 0.0149″0.38 mm | 0.0156″0.40 mm | 0.0187″0.47 mm |
| 29▸gauge | 0.0113″0.29 mm | 0.0135″0.34 mm | 0.0141″0.36 mm | 0.0172″0.44 mm |
| 30▸gauge | 0.0100″0.25 mm | 0.0120″0.30 mm | 0.0125″0.32 mm | 0.0157″0.40 mm |
Gauge thicknesses are nominal reference values from the published standard for each metal. Mill tolerance still applies — ASTM B209 for aluminum, A1008/A1011 for carbon steel, A480 for stainless, A653 for galvanized. Galvanized thicknesses include the zinc coating; the standard has no published gauge below 8. The green stock chips show the actual decimal thickness we hold, which is what we cut and what we quote.
Find a quick answer for uncoated carbon steel. Use the four-material chart for stainless, aluminum, or galvanized steel; the same gauge number does not mean the same thickness.
0.1345 in3.42 mm
10 gauge mild steel is 0.1345 inches (3.42 mm) nominal. This value is for uncoated carbon steel; stainless steel, galvanized steel, and aluminum use different thicknesses for the same gauge.
0.1196 in3.04 mm
11 gauge mild steel is 0.1196 inches (3.04 mm) nominal. This value is for uncoated carbon steel; stainless steel, galvanized steel, and aluminum use different thicknesses for the same gauge.
0.1046 in2.66 mm
12 gauge mild steel is 0.1046 inches (2.66 mm) nominal. This value is for uncoated carbon steel; stainless steel, galvanized steel, and aluminum use different thicknesses for the same gauge.
0.0747 in1.90 mm
14 gauge mild steel is 0.0747 inches (1.90 mm) nominal. This value is for uncoated carbon steel; stainless steel, galvanized steel, and aluminum use different thicknesses for the same gauge.
0.0598 in1.52 mm
16 gauge mild steel is 0.0598 inches (1.52 mm) nominal. This value is for uncoated carbon steel; stainless steel, galvanized steel, and aluminum use different thicknesses for the same gauge.
0.0478 in1.21 mm
18 gauge mild steel is 0.0478 inches (1.21 mm) nominal. This value is for uncoated carbon steel; stainless steel, galvanized steel, and aluminum use different thicknesses for the same gauge.
0.0359 in0.91 mm
20 gauge mild steel is 0.0359 inches (0.91 mm) nominal. This value is for uncoated carbon steel; stainless steel, galvanized steel, and aluminum use different thicknesses for the same gauge.
0.0299 in0.76 mm
22 gauge mild steel is 0.0299 inches (0.76 mm) nominal. This value is for uncoated carbon steel; stainless steel, galvanized steel, and aluminum use different thicknesses for the same gauge.
Nominal inch values use the same data as the converter. Millimeters are calculated from those values and rounded to two decimals. See the reference and rounding notes.
Use the column for the material you intend to buy. The nominal number and the catalog thickness can differ, even before mill tolerance is considered.
Choosing material for a formed part? Compare 5052-H32 and 6061-T6 aluminum, then use the sheet metal prototyping checklist to specify thickness, bends and inspection requirements together.
Aluminum sheet is gauged on the Brown & Sharpe (AWG) scale. Carbon steel uses the Manufacturers’ Standard Gauge. They are not interchangeable, and the gap widens as the sheet gets thicker:
16 ga aluminum = 0.0508″ but 16 ga mild steel = 0.0598″ — about an 18% difference in thickness. Stiffness and bend force also depend on the material and geometry.
For example, this chart lists 14 gauge aluminum at 0.0641 inches. A 0.063-inch aluminum sheet is a nearby decimal stock thickness, not exactly the same nominal value. Specify which dimension your part requires.
The fix is simple: specify aluminum by decimal thickness. Put 0.063″ on the drawing and in the quote, never “16 ga.” Every aluminum SKU in our catalog carries its decimal thickness for exactly this reason, and the instant quote prices off the decimal. Where you see a gauge number next to an aluminum thickness on this site, treat it as a shop-floor shorthand, not a spec.
Numbers on a chart flatten out. Stack the gauges next to each other at true relative thickness — against a dime, a credit card, a sheet of paper — and the choice between 14 and 18 gauge stops being abstract.
Choose up to six gauges. All bars share the same scale; reference objects are approximate.
Gauge is a trade between stiffness, weight, bend force, and cost. These bands are where most laser-cut sheet metal parts land. Thicknesses shown are mild steel — use the chart above to convert for your metal.
Compare these thicknesses for mounting plates, frames, and brackets. Capacity still depends on the material, span, joints, and loads; a gauge number alone does not qualify a load-bearing design.
Compare these thicknesses for brackets, chassis, and enclosures. Check both finished stiffness and the support available during forming before choosing the stock.
Useful options to compare for covers, panels, and light brackets. Check unsupported spans, fastening method, finish, and bend geometry rather than selecting on gauge alone.
Consider for lightweight covers, decorative panels, and shields. Large unsupported faces may need stiffening features; review flatness and handling requirements.
Thin sheet can suit shims, trim, and shielding. Review handling, cut quality, and thickness tolerance for the specific alloy and application.
Compare decimal thicknesses listed in the Xeon NC catalog. Catalog entries and tooling references support design planning; confirm current availability and the manufacturing setup in your quote.
Compare gauge numbers, convert to millimeters, and separate nominal thickness from the requirements on your drawing.
The chart uses common U.S. sheet-metal gauge references. It is not a wire, tube-wall, or thickness-tolerance chart.
Steel, stainless, galvanized steel, and aluminum have separate columns. Values are nominal, and some suppliers round them differently. The displayed millimeter values are converted from this chart’s inch values using 25.4 mm per inch.
Gauge does not specify grade, temper, coating, or allowable thickness variation. For a fit or tolerance stack, use the ordered decimal thickness and the applicable supplier specification.
Need a cut or bent part? Send a DXF or STEP with the material and required thickness for a sheet metal quote.
Choose the thickness.
Make the part.
Bring your DXF or STEP file and specify your material by its decimal thickness.
